DRO LCD Screen Digital Readout Display for CNC Milling Machine & Mini Lathe - High Precision Tool Measurement System | Perfect for Metalworking, Woodworking, and DIY Projects

Product Description

WHY YH800-3A mini LCD DRO If you run a mini lathe, mini drilling milling machine you will face pain while selecting a proper position readout, because the normal DROs are way too Big, and it is so hard to you to install a linear encoder, A10 mini LCD DRO however is just the right mini digital readout that solves your problem, A10 simply wins customers’ good feedback from all over the world, as it gives convenience to machining, it is more readable than traditional LED DROs, it is very good while operating in the dark environment, and it can also be enabled to dark mode to protect machinist’s eyes. Get your A10 mini digital readout today. New ideas Our designers are designing YH800-3A with white front cover and black rear cover. Such a contrasting color makes the product more unique and attractive. power supply Although our mini digital readout is small in size, it still has a built-in power supply, and uses Taiwan MW Mingwei power supply DB9 PLUG We still use the DB9 aviation plug, and the pin definition is Pin2 0v Pin6 A PIN7 5V PIN B PIN 9 Read more Ergonomic operation way 3.5 inch color LCD display Mini digital readout A10 by YHSINO is available on 1 axis,2 axis,3 axis. Multiple background colors Languages available in English, German, Polish, Hungarian, Russian, Ukrainian, Simplified Chinese, Traditional Chinese, Thai, Italian, Portuguese, Greek…; More to come! Power Dissipation: 15W Voltage Range: AC80V-260V / 50HZ-60HZ Operating Keypad: Mechanical Keypad Input Signal:5V TTL or 5V RS422 Input Frequency: ≤4MHZ Resolution Supported For Linear Encoder: 0.1μm、0.2μm、0.5μm、1μm、2μm、2.5μm、5μm、10μm Resolution Supported For Rotary Encoder: ＜1000000 PPR 100 sets of SDM Coordinates REF function Centering / 1/2 PLD PCD Radius and Diameter Conversion Axis Summing Taper Measuring Linear Measuring Basing Rotary Encoder EDM Function (Optional, Pre-Order only) RS232 Interface (Optional, Pre-Order only) Rotation Speed Measuring (Optional, Pre-Order only) Features Zeroing, Data Recovery Preset value Metric and Imperial switch Power-off memory Encoder selection(Linear or Rotary) Linear Compensation & Non-linear compensation Counting Direction Setting ABS/INC Coordinate Read more
